Epiphan Pearl-2

Raspoloživost Sarajevo: Isporuka 20-30 dana
SKU
ESP1150

The Pearl-2 Base Video Mixer from Epiphan is a powerful live-production mixer that lets you create visually appealing live video programs by combining, encoding, switching, and recording up to six video sources and two audio sources.

18.479,50 KM 15.794,44 KM

Sadržaj pakovanja

  • Epiphan Pearl-2 Base Video Mixer
  • Ethernet Cable
  • Power Cable (6')
  • SDI Cable (3')
  • HDMI Cable (3')
  • DVI (F) to HDMI (M) Adapter
  • Hard-Shell Carrying Case

The Pearl-2 Base Video Mixer from Epiphan is a powerful live-production mixer that lets you create visually appealing live video programs by combining, encoding, switching, and recording up to six video sources and two audio sources. With Pearl-2 you can share any kind of video, anytime, anywhere. Simple to use with a web-based portal for initial configuration, you get a drag and drop interface to create completely customizable layouts for your live stream. You can choose to keep Pearl-2's default encoding settings or customize them to meet your exact needs. Control the video recorder and video switcher capabilities via the touchscreen or the tablet-friendly Epiphan Live interface.

Key Features

  • Reliable, simple live streaming with Pearl-2's integrated live video production workflow
  • Works with video sources from SD to 4K (separate add-on required for 4K)
  • Connect up to six sources at once to encode and stream one 4K Ultra HD program, or up to six 1080p Full HD programs
  • Use any combination of your video sources connected to the HDMI, 4K HDMI, or 12G-SDI video input ports, or from IP cameras over your network
  • Sixth generation Intel i7 processor
  • Use the touchscreen or Epiphan Live to preview and change the live content in your video programs
  • See changes immediately in your live video stream, and on displays connected to Pearl-2’s 4K HDMI video output ports
  • Simultaneously send live stream to YouTube, Facebook, and any other CDN or video portal
  • At the same time, use the built-in streaming server to stream locally to web browsers, smart TVs, and set-top boxes
  • Control your streaming and recording from any mobile device or computer on your local network
  • Capture embedded HDMI and SDI audio, or use the XLR/RCA ports for professional level audio from mixing consoles and sound equipment
  • Built-in attenuation and gain adjustment
  • Design your own custom layouts, including picture-in-picture, by using the drag and drop editor in Pearl-2’s web-based Admin panel
  • Combine, crop, and scale up to six video sources
  • Customize the video source completely with backgrounds, overlay images, text, and timestamping
  • Hold hundreds of hours of HD recordings on the 512GB solid-state hard drive
  • Configure automatic file transfer to a networked storage or local USB drive via USB 3.0, to ensure your files are always protected
  • Connect your headphones and monitor audio using the front-mounted 3.5mm audio jack and on-screen VU meter
  • Send the content to a larger confidence monitor with Pearl-2’s two 4K HDMI video output ports
  • Use Pearl-2’s built-in streaming server to share via unicast or multicast stream to up to 50 viewers with popular streaming protocols such as HTTP, HLS, FLV, ASF, UPnP, and SAP
  • Publish your live video stream to a large audience using an enterprise streaming server or CDN using RTMP or
  • RTSP
  • Supported CDNs including Facebook Live, YouTube, Wowza, Livestream, Akamai, Ustream, and more
  • Stream your final program output, in any desired resolution, while also recording high quality ISOs for post-processing
  • Pearl-2 integrates easily with content management systems (CMS) and with learning management systems (LMS) such as Blackboard, Kaltura, Mediasite, and Moodle

Processing

Processing Resolution DCI 4K

Input

Video Input Connectors 2 x BNC (12G-SDI)
4 x HDMI (DVI / HDMI 1.4a)
1 x RJ45 (HX / NDI)
Audio Input Connectors 4 x 3-Pin XLR Stereo Analog Female
1 x 2RCA Stereo Analog Female

Output

Video Output Connectors 1 x HDMI (HDMI 1.4a)
1 x HDMI (HDMI 2.0)
Audio Output Connectors 1 x 1/8" / 3.5 mm TRS Stereo Analog Female
Embedded Audio Output HDMI

Connectivity

HDCP Support Yes

IP Encoding/Decoding

IP Video H.264:
4096 x 2160 Encoding

Internal Recording

Internal Storage 512 GB

Display

Screen size 800x480
Display Size 4.3"

Power

Power Consumption Device: 100 to 240 VAC
Built-In Battery None

Environmental

Operating Temperature 32 to 104°F / 0 to 40°C

General

Dimensions 11.81 x 9.45 x 3.54" / 30 x 24 x 8.99 cm
Weight 8.4 lb / 3.8 kg
